MCP9700AT-E/TT
SENSOR TEMP ANLG VOLT SOT-23-3
型号
MCP9700AT-E/TT
制造商/品牌
系列
-
零件状态
Active
包装
Tape & Reel (TR)
工作温度
-40°C ~ 125°C
安装类型
Surface Mount
特征
-
封装/箱体
TO-236-3, SC-59, SOT-23-3
输出类型
Analog Voltage
供应商器件封装
SOT-23-3
解决
10mV/°C
电压 - 电源
2.3 V ~ 5.5 V
传感器类型
Analog, Local
测试条件
0°C ~ 70°C (-40°C ~ 125°C)
感测温度 - 本地
-40°C ~ 125°C
感应温度 - 远程
-
准确度 - 最高（最低）
±2°C (-2°C, +4°C)
