ADRF5040BCPZ-R7
HIGH ISOLATION,SP4T,9KHZ -12GHZ
型号
ADRF5040BCPZ-R7
制造商/品牌
系列
-
零件状态
Active
包装
Tape & Reel (TR)
工作温度
-40°C ~ 85°C
特征
-
封装/箱体
24-VFQFN Exposed Pad
阻抗
50 Ohm
供应商器件封装
24-LFCSP (4x4)
电压 - 电源
3.3V
电路
SP4T
拓扑
Absorptive
1分贝
37dBm
射频类型
VSAT
频率 - 较低
9kHz
频率 - 上限
12GHz
隔离度@频率
34dB @ 8GHz
插入损耗@频率
0.8dB @ 8GHz
中间型第三阶段
53dBm (typ)
